Dazen Note3 -A01
Available·June 2015·Android·Phone
Storage
16GB 2GB RAM
Your Status
Key Specifications
Key Specifications
Display
5.5"
Color IPS TFT LCD display
720x1280 · 267 PPI
Chipset
MediaTek MT6753
28 nm · octa-core · 1.4 GHz
ARM Mali-T720MP3
Google Android 5.1 (Lollipop)
Released 2015 Jul
Memory
RAM
2GB
LPDDR3 SDRAM
Storage
16GB
Camera System
Wide
12.8 MP
1920x1080 pixel
Selfie
5.0 MP
1280x720 pixel
Battery
3000 mAh battery
Connectivity
Wi-Fi 4 (n)
Bluetooth 4.0
USB 2.0
Build
2.81x5.55x0.37 inches
3.5mm JackMicroSD
Full Specifications
Technology
GSM / HSPA / LTE
2G bands
GSM 900 / 1800 / 1900
3G bands
UMTS 2100 / 1900 / 850 / 900 - HSUPA, HSDPA, HSPA+ 21.1, TD-HSDPA
4G bands
LTE bands 1, 3, 7, 38, 39, 40, 41 - 150/50 data links
Dual SIM
SIM2 supports same bands as SIM1
Status
Available. Released 2015 Jul
Dimensions
141 × 71.5 × 9.3 mm
Build
No
SIM
Micro-SIM (3FF)
Type
Color IPS TFT LCD display, 16.8M colors
Size
5.5 inches
Resolution
720x1280 pixels (~267 PPI density), ~82.7% screen-to-body ratio
Protection
No
Touch
Capacitive multi-touch screen
OS
Google Android 5.1 (Lollipop)
Chipset
MediaTek MT6753 28 nm
CPU
1.4 GHz octa-core
GPU
ARM Mali-T720MP3
Card slot
microSD
Internal
16GB 2GB RAM
Single
12.8 MP, 1.0 x optical zoom
Focus
CD AF
Sensor
CMOS
Features
HDR photo, Macro mode, Panorama Photo, Face detection, single LED flash
Video
1920x1080 pixel
Single
5.0 MPsec. cam
Video
1280x720 pixel
Loudspeaker
mono
3.5mm jack
Yes
FM radio
FM radio (88-108 MHz)
Audio features
Voice speaker, Speakerphone, VoLTE
WLAN
802.11b, 802.11g, 802.11n
Bluetooth
Bluetooth 4.0
Positioning
Simultaneous GPS, A-GPS, Geotagging, QuickGPS
Satellite details
GLONASS (L1OF)
NFC
No
USB
USB Micro-B (Micro-USB) USB 2.0
USB features
USB charging
Wireless features
Miracast, Wi-Fi Direct, Wi-Fi Tethering
Sensors
FP sensor, L sensor, P sensor
Type
3000 mAh battery Li-ion polymer (LiPo)
