Key Specifications
Key Specifications
Display
4"
Color TN-TFT LCD display
480x800 · 233 PPI
Chipset
Qualcomm Snapdragon 200 MSM8212
45 nm · quad-core · 1.2 GHz
Qualcomm Adreno 302
Microsoft Windows Phone 8.1
Released 2015 Feb 19
Memory
RAM
1GB
LPDDR2 SDRAM
Storage
8GB
eMMC 4.5
Camera System
Wide
5.0 MP
848x480 pixel
Selfie
0.3 MP
640x480 pixel
Battery
1560 mAh battery
Connectivity
Wi-Fi 4 (n)
Bluetooth 4.0
USB 2.0
Build
136.3 g
2.58x4.68x0.46 inches
3.5mm JackMicroSD
Full Specifications
Technology
GSM / HSPA
2G bands
GSM 850 / 900 / 1800 / 1900
3G bands
UMTS 2100 / 1900 / 850 / 900 bands - HSUPA, HSUPA 5.8, HSDPA, HSPA+ 21.1, HSPA+ 42.2 data links
Dual SIM
SIM2 supports same bands as SIM1
Status
Available. Released 2015 Feb 19
Dimensions
118.9 × 65.5 × 11.6 mm
Weight
136.3 g
Build
No
SIM
Micro-SIM (3FF)
Type
Color TN-TFT LCD display, 16.8M colors
Size
4.0 inches
Resolution
480x800 pixels (~233 PPI density), ~58.5% screen-to-body ratio
Protection
No
Touch
Capacitive multi-touch screen
OS
Microsoft Windows Phone 8.1
Chipset
Qualcomm Snapdragon 200 MSM8212 45 nm
CPU
1.2 GHz quad-core
GPU
Qualcomm Adreno 302
Card slot
microSD
Internal
8GB 1GB RAM
eMMC 4.5
Single
5.0 MP, 1.0 x optical zoom
Focus
No
Sensor
CMOS
Features
Panorama Photo, Face detection, No flash, HDR
Video
848x480 pixel
Single
0.3 MPsec. cam
Video
640x480 pixel
Loudspeaker
mono
3.5mm jack
Yes
FM radio
FM radio (88-108 MHz) with RDS
Audio features
Voice speaker, Speakerphone
WLAN
802.11b, 802.11g, 802.11n
Bluetooth
Bluetooth 4.0
Positioning
A-GPS, Geotagging, QuickGPS
NFC
No
USB
USB Micro-B (Micro-USB) USB 2.0
USB features
USB charging
Wireless features
Wi-Fi Tethering
Sensors
L sensor, P sensor
Type
1560 mAh battery Li-ion
