Specifications
Connectivity
Bluetooth 1.2Proprietary USB 1.1
- Dual SIM
- SIM2 supports same bands as SIM1
- Status
- Available. Released 2006 Sep 4
- Dimensions
- 97.5 × 51.5 × 19.8 mm
- Weight
- 111 g
- Build
- No
- Type
- Color TN-TFT LCD display, 262144 colors
- Size
- 2.2 inches
- Resolution
- 240x320 pixels (~181 PPI density), ~30.0% screen-to-body ratio
- Protection
- No
- Secondary Number of Display Colors/Scales
- 65536
- OS
- Microsoft Windows Mobile 5.0 for Smartphone
- Chipset
- Intel XScale PXA270 (Bulverde)
- CPU
- 0.31 GHz single-core
- GPU
- N/A
- Card slot
- microSD
- Internal
- 128 MiB
- Single
1.3 MP, 1.0 x optical zoom, CMOS
- Other features
- single LED flash
- Video
- 176x144 pixel
- Secondary Camera Sensor
- No
- Loudspeaker
- mono
- 3.5mm jack
- No
- Audio features
- Voice speaker, Speakerphone
- Bluetooth
- Bluetooth 1.2
- NFC
- No
- USB
- Proprietary USB 1.1
- Serial
- RS-232
- Serial Connector
- Proprietary
- Serial Data Rate
- 115200 bps
- Keyboard
- Built-in numeric
- Number of keys
- 18
- Directional Pad
- 5-way
- Type
- 950 mAh battery Li-ion
- Endurance
- 12.0 hours
- Models
- PN-820
- Countries
- USA
- Type
- Color TN-TFT LCD 2nd display
- Size
- 1.1 inches
- Resolution
- 96x96 pixels (~127 PPI density)
